Parameter Details
12
12.7 H: TERMINALS
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 755
Figure 12.114 Virtual Analog I/O Functional Block Diagram
Figure 12.115 Virtual Digital I/O Functional Block Diagram
Note:
• Refer to H1-xx "DI Setting Values" for more information on the virtual digital input setting values.
• Refer to H2-xx "DO Setting Values" for more information on the virtual digital output setting values.
• Refer to H3-xx "AI Setting Values" for more information on the virtual analog input setting values.
• Refer to H4-xx "AO Setting Values" for more information on the virtual analog output setting values.
• 5 [3-Wire Seq.] and 20 to 2F [External Fault] cannot be selected in H7-01 to H7-04 [Virtual In1 Select Function to Virtual In4 Select
Function].
• If the terminal is not used, set H7-01 to H7-04 = 0. However, the through mode function is not supported.
• The virtual I/O function selection and the multi-function input for DI-A3 cannot be used simultaneously.
■ H7-00 Virtual MFIO Selection
No.
(Hex.)
Name Description
Default
(Range)
H7-00
(116F)
Expert
Virtual MFIO Selection
Sets the function to enable and disable the virtual I/O function. Set this parameter to 1 to operate
the virtual I/O function.
0
(0, 1)
0 : Disabled
1 : Enabled
■ H7-01 Virtual In1 Select Function
No.
(Hex.)
Name Description
Default
(Range)
H7-01
(1185)
Expert
Virtual In1 Select Function
Sets the function that enters the virtual input set in H7-10 [Virtual Out1 Select Function].
0
(0 - 4, 6 - 19F)
■ H7-02 Virtual In2 Select Function
No.
(Hex.)
Name Description
Default
(Range)
H7-02
(1186)
Expert
Virtual In2 Select Function
Sets the function that enters the virtual input set in H7-12 [Virtual Out2 Select Function].
0
(0 - 4, 6 - 19F)
■ H7-03 Virtual In3 Select Function
No.
(Hex.)
Name Description
Default
(Range)
H7-03
(1187)
Expert
Virtual In3 Select Function
Sets the function that enters the virtual input set in H7-14 [Virtual Out3 Select Function].
0
(0 - 4, 6 - 19F)
