12.11 T: AUTOTUNING
854 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
■ T4-06 Motor Rated Voltage
No.
(Hex.)
Name Description
Default
(Range)
T4-06
(3135)
Motor Rated Voltage
Sets the rated voltage (V) of the motor.
400 V Class: 400.0 V
(400 V Class: 0.0 - 510.0
V)
■ T4-07 Motor Rated Current
No.
(Hex.)
Name Description
Default
(Range)
T4-07
(3136)
Motor Rated Current
Sets the rated current (A) of the motor.
Determined by o2-04 and
C6-01
(10% to 200% of the drive
rated current)
Note:
The value set here becomes the base value for motor protection, the torque limit, and torque control.
■ T4-08 Motor Rated Capacity
No.
(Hex.)
Name Description
Default
(Range)
T4-08
(3137)
Motor Rated Capacity
Sets the motor rated output in the units from o1-58 [Mot Capacity Unit].
Determined by E9-10
(0.10 - 650.00 kW)
■ T4-09 Motor Poles Number
No.
(Hex.)
Name Description
Default
(Range)
T4-09
(3138)
Motor Poles Number
Sets the number of motor poles.
Determined by E9-01
(2 - 48)
