R&S RTC1000 User Manual

Remote Commands Reference
R&S
®
RTC1000
227User Manual 1335.7352.02 ─ 02
RMS (Root Mean Square) value of the voltage of the complete
displayed waveform of the selected channel.
RTIMe | FTIMe
Rise or falling time of the left-most rising edge within the dis-
played section of the waveform of the selected channel. The ref-
erence level for this mesurement is set with REFLevel<m>:
RELative:MODE.
PDCycle | NDCycle
Measure the positive or negative duty cycle.
PPWidth | NPWidth
Measure the width of positive or negative pulses.
CYCMean
Mean value of the left-most signal period of the waveform of the
selected channel.
CYCRms
RMS (Root Mean Square) value of the voltage of the left-most
signal period of the waveform of the selected channel.
STDDev
Measures the standard deviation of the waveform.
CYCStddev
Measures the standard deviation of one cycle, usually of the
first, left-most signal period.
TFRequency | TPERiode
Measure the frequency of the trigger signal and the length of the
its periods (hardware counter).
DELay
Time difference between two edges of the same or different
waveforms. The waveforms are selected with
MEASurement<m>:SOURce, and the edges with
MEASurement<m>:DELay:SLOPe.
PHASe
Phase difference between two waveforms (time difference/
period * 360).
BWIDth
Duration of one burst, measured from the first edge to the last.
POVershoot | NOVershoot
Positive and negative overshoot of a square wave.
*RST:
NONE (measurement is off)
The waveforms are selected with MEASurement<m>:SOURce
MEASurement<m>:RESult? [<MeasType>]
Returns the result of the specified measurement type.
Measurements
