Remote Commands Reference
R&S
®
RTC1000
228User Manual 1335.7352.02 ─ 02
Suffix:
<m>
.
1..6
Selects the measurement place.
Query parameters:
<MeasType> FREQuency | PERiod | PEAK | UPEakvalue | LPEakvalue |
PPCount | NPCount | RECount | FECount | HIGH | LOW |
AMPLitude | CRESt | MEAN | RMS | RTIMe | FTIMe | PDCYcle |
NDCYcle | PPWidth | NPWidth | CYCMean | CYCRms |
STDDev | TFRequency | TPERiode | DELay | PHASe | BWIDth |
POVershoot | NOVershoot
Specifies the measurement type. See MEASurement<m>:MAIN.
Return values:
<Value> Measurement result
Usage: Query only
MEASurement<m>:DELay:SLOPe <SignalSlope>,<ReferenceSlope>
Sets the edges to be used for delay measurement. The associated waveforms are
defined with MEASurement<m>:SOURce
Parameters:
<SignalSlope> POSitive | NEGative
Slope of source 1 ( first waveform)
*RST: POS
<ReferenceSlope> POSitive | NEGative
Slope of source 2 (second waveform)
*RST: POS
REFLevel<m>:RELative:MODE <RelativeMode>
Sets the lower and upper reference levels for rise and fall time mesurements (cursor
and automatic mesurements), defined as percentages of the high signal level.
Suffix:
<m>
.
1..5
Measurement to which the reference level belongs.
Suffix 1...4 assign the measurement places 1 to 4 (auto mea-
sure).
Suffix 5 assigns the cursor mesurement.
Measurements
