The jack is designed for wheel
changing only. Never work
beneath the vehicle with the jack
as the only means of support.
Always use correctly rated vehicle
support stands, before putting
any part of your body beneath the
vehicle.
Keep your hands and clothing
away from drive belts, pulleys,
and fans. Some fans may continue
to operate or start operating after
the engine has stopped.
Remove metal wristbands and
jewellery, before working in the
engine compartment.
Do not touch electrical leads or
components while the engine is
running, or the vehicle's ignition
is switched on.
Do not allow tools or metal parts
of the vehicle to make contact
with the battery leads or
terminals.
POISONOUS FLUIDS
Fluids used in motor vehicles are
poisonous and should not be consumed
or brought into contact with open wounds.
For your own safety, always read and obey
all instructions printed on labels and
containers.
USED ENGINE OIL
Prolonged contact with engine oil may
cause serious skin disorders, including
dermatitis and cancer of the skin. Always
wash thoroughly after contact.
It is illegal to pollute drains,
watercourses or soil. Use
authorised waste disposal sites
to dispose of used oil and toxic
chemicals.
OPENING THE BONNET
1. Pull the bonnet release lever, located
in the left side front footwell.
2. Lift the bonnet safety catch, located
below the centre point of the bonnet,
then raise the bonnet.
CLOSING THE BONNET
Do not drive with the bonnet
retained by the safety catch
alone.
1. Lower the bonnet until the safety catch
engages.
2. Using both hands, press the bonnet
down until the catches click.
3. Check that both catches are engaged
by trying to lift the front edge of the
bonnet.
200
Maintenance
© Jaguar Land Rover Limited 2015
