EXTERIOR MIRRORS
1. Mirror selector switches: Press to select
the left or right mirror.
2. Mirror adjustment switch: Move up/
down/left or right to adjust the mirror's
glass position.
3. Press both mirror selector switches
together to fold/unfold the mirrors
(power-fold option).
The mirrors can be adjusted and folded
when the ignition is on and for up to 5
minutes after the ignition is switched off,
provided the driver’s door is not opened.
Note: Power-fold will operate only if the
vehicle's speed is below 113 km/h (70
mph).
Note: A thermal cut-out will temporarily
disable the power-fold feature if the
switches are operated repeatedly.
Note: The rear-view door mirror heaters
operate automatically according to the
external temperature and windscreen
wiper operation.
Note: An amount of knock protection is
designed into the door mirrors. If a mirror
is accidentally knocked inwards or
manually folded inwards, the mirror head
will be disengaged from the folding
mechanism. To re-engage the mechanism,
fold then unfold the mirror using the
switch.
The mirrors can be configured
by a Retailer/Authorised
Repairer to automatically fold
when the vehicle is locked, and
unfold when it is unlocked.
Note: If the mirrors were folded using the
switches, they will not unfold when the
vehicle is unlocked.
69
Mirrors
