Range Rover Evoque - ENGINE COMPARTMENT FUSE BOX

ENGINE COMPARTMENT FUSE BOX
Circuits protectedFuse
colour
Rating
(Amps)
Fuse
number
Starter motor (2.2L diesel).Tan51
Engine management system (2.0L petrol).Green30
Electrical power management.Tan52
Power steering.-803*
Glow plugs (diesel).-604*
Engine cooling fans.-1005*
Engine management system (2.0L petrol. 2.2L diesel).Blue156
Engine management system (2.0L diesel).Red10
---7
Engine management system (2.0L petrol. 2.2L diesel).Yellow208
Engine management system (2.0L diesel).Blue15
Engine management system (2.0L diesel. 2.2L diesel),
Diesel Exhaust Fluid (DEF) (2.0L diesel).
Red109
---10
Engine management system.Red1011
Engine management system (2.0L petrol. 2.2L diesel).Blue1512
Engine management system (2.0L diesel).Red10
---13
Engine management system (2.0L petrol. 2.2L diesel).Blue1514
Engine management system (2.0L diesel).Red10
Starter motor.Green4015*
Heater.-10016*
Passenger compartment fuse box.-6017*
Passenger compartment fuse box.-6018*
Luggage compartment fuse box.-6019*
Luggage compartment fuse box.-6020*
Electrical power management.-6021*
Front wipers.Green3022*
228
