Range Rover Evoque - REAR LAMP BULB REPLACEMENT; REAR FOG LAMP BULB REPLACEMENT

Reverse the removal procedure to install
a new bulb.
REAR LAMP BULB
REPLACEMENT
1. Remove the 2 fixings.
2. Reversing lamp:
Turn the bulb holder counter-clockwise
and pull to remove it from the lamp
unit. Grip the holder then press the
bulb into the holder and turn counter-
clockwise to release the bulb. Pull the
bulb up to remove.
Note: Note the orientation of the bulb
unit to aid refitting.
Reverse the removal procedure to install
a new bulb.
REAR FOG LAMP BULB
REPLACEMENT
Always find a safe place to stop,
off the highway and away from
traffic.
Apply the parking brake. Engage
Park (P) on automatic vehicles,
select first or reverse gear on
manual vehicles.
Switch on the hazard warning
lamps.
Place a warning triangle at a
suitable distance behind the
vehicle, facing towards oncoming
traffic.
Disconnect trailer/caravan from
vehicle.
Make sure all passengers, and
animals, are out of the vehicle and
in a safe place away from the
highway.
If the vehicle has been driven
recently, do not touch exhaust
system components until they
have cooled.
Access to a rear fog lamp housing is from
beneath and behind the rear bumper. The
bulb holder is a black plastic unit that
incorporates the bulb. No tools are
required but a torch may be of use.
1. To remove the bulb holder, press in
the outer wings on the black plastic
unit and pull the holder free of the
housing.
2. To separate the bulb holder from the
electrical connector, first push up the
connector lock.
208
