INSTRUMENT PANEL
1. Speedometer.
2. Tachometer.
3. Message centre and menu.
Note: The display in this area of the
Instrument panel can be changed to
suit your personal preferences. See
49, INSTRUMENT PANEL MENU.
4. Fuel gauge: See 57, LOW FUEL
WARNING (AMBER).
As a reminder for the location of the
fuel filler, there is an arrow next to the
fuel pump symbol pointing to the
relevant side of the vehicle.
Never allow the engine to run out
of fuel, or damage to the engine
may occur.
5. Gear selector status.
6. Temperature gauge: If the
temperature gauge pointer moves into
the red section at the top of the scale,
the engine is overheating. Stop the
vehicle as soon as safety permits and
allow the engine to idle until the
temperature reduces. If, after several
minutes, the temperature does not
reduce, switch off the engine and allow
it to cool. If the problem persists, seek
qualified assistance immediately.
Serious engine damage can occur
if the vehicle is driven while the
engine is overheating.
Note: If engine overheating occurs,
there may be a noticeable reduction
in engine power and the air
conditioning may cease operation. This
is a normal operating strategy, to
reduce load on the engine and assist
with cooling.
7. Warning lamps and indicators display:
Other warning lamps are displayed in
the speedometer and tachometer.
INSTRUMENT PANEL MENU
49
Instrument panel
