Power (Watts)SpecificationLamp
60HB3Halogen headlamp - low and high beam
24PSY24WSV+Halogen headlamp - direction indicators
24PSY24WSV+Xenon headlamp - direction indicators
16W16WReverse lamps
19PS19WRear fog lamps
All other exterior lamps and some interior
lamps are either LED (Light Emitting
Diode) or Xenon and can only be renewed
by a Retailer/Authorised Repairer.
All replacement procedures require the
removal of components to gain access to
the bulbs.
Moving a headlamp unit should be
undertaken only by a qualified
technician. If in doubt, consult a
Retailer/Authorised Repairer.
Note: To change any bulb in a headlamp
unit, a cross head screwdriver and a 10
mm spanner is required.
XENON LAMPS
High voltage is required to ignite
the gas and metal vapour which
are used to power Xenon lamps.
Contact with this voltage can
cause serious injury. Replacement
or maintenance of Xenon lamps
should only be carried out by
suitably qualified personnel.
Xenon lamp units operate at a
very high temperature. Make sure
the lamp units have cooled before
attempting to touch them.
Xenon lamp units contain mercury
which is highly toxic and can be
extremely harmful.
Seek advice about the correct disposal of
Xenon lamp units from a Retailer/
Authorised Repairer, or your local
authority.
203
Maintenance
© Jaguar Land Rover Limited 2015
