Range Rover Evoque - CONNECTING A STARTING AID

1. Connect the positive (Red) jump lead
to the recommended positive (+)
boost terminal on the donor vehicle.
Note: Refer to the donor vehicle's
handbook for the recommended
positive boost terminal.
2. Connect the other end of the positive
(Red) jump lead to the positive (+)
terminal on the discharged battery.
3. Connect the negative (Black) jump lead
to the recommended negative (-)
boost terminal of the donor vehicle.
Note: Refer to the donor vehicle's
handbook for the recommended
negative boost terminal.
4. Connect the other end of the negative
(Black) jump lead to the earth point on
the disabled vehicle (as illustrated).
Note: Check that all cables are clear
of any moving components and that
all 4 connections are secure.
5. Start the engine of the donor vehicle
and allow it to idle for a few minutes.
6. Start the engine of the disabled
vehicle.
Note: Do not switch on any electrical
circuits of the disabled vehicle until
after the jump leads are removed.
7. Allow both vehicles to idle for 2
minutes.
8. Switch off the donor vehicle.
9. Disconnect the negative (Black) jump
lead from the previously disabled
vehicle.
10.Disconnect the negative (Black) jump
lead from the donor vehicle.
11.Disconnect the positive (Red) jump
lead from the previously discharged
battery.
12.Disconnect the positive (Red) jump
lead from the donor vehicle.
CONNECTING A STARTING AID
To start the vehicle using a starting aid or
a slave battery, follow the instructions in
the sequence given:
1. Connect the positive (Red) jump lead
to the positive (+) battery terminal of
the discharged battery.
2. Connect the negative (Black) jump lead
to the vehicle's earth point.
3. Switch on the starting aid.
4. Start the engine and allow it to idle.
5. Disconnect the negative (Black) jump
lead from the vehicle's earth point.
6. Switch off the starting aid.
223
Vehicle battery
