When a fuse box lid is removed,
take care to protect the box from
moisture, and refit the lid at the
earliest opportunity.
Access can be gained to the fuses as
follows:
1. Engine compartment fuse box.
• To gain access to the fuse box:
Remove the 2 plastic fixings (see
illustration) and pull the tube up to
release it from the air box.
• Unlatch the tabs (arrowed) to
release the fuse box cover.
The engine compartment fuse
numbers and positions are shown
on the inside of the fuse box cover.
2. Passenger compartment fuse box
(upper): Open the glove box and
remove the panel from the glove box
liner. A label on the panel shows the
circuits protected and the fuse
locations.
3. Passenger compartment fuse box
(lower): Remove the lower access
panel.
4. Luggage compartment (upper and
lower) fuse boxes: Remove the panel
from the left side trim of the luggage
compartment. A label on the panel
shows the circuits protected and the
fuse locations.
5. Luggage compartment (underfloor)
fuse box (if fitted): Lift the luggage
compartment floor and remove the
spare wheel/tyre repair kit housing (see
illustration). The fuse numbers are
displayed on the fuse box.
CHANGING A FUSE
Always switch off the ignition
system, and the affected electrical
circuit, before replacing a fuse.
Fit Land Rover approved
replacement fuses of the same
rating and type, or fuses of a
matching specification. Using an
incorrect fuse, may result in damage
to the vehicle's electrical system
and can result in a fire.
If the replacement fuse blows after
fitment, the system should be
checked by your Retailer/
Authorised Repairer.
Note: It is recommended that relays
should only be renewed by qualified
persons.
The fuse removal tweezers are located in
the passenger compartment fuse box.
Press the tweezers onto the head of a fuse
and pull to remove. A break in the wire
inside the fuse indicates that the fuse has
blown and must be renewed.
There are some spare replacement fuses
in the passenger compartment fuse box.
See the fuse box label for details.
227
Fuses
© Jaguar Land Rover Limited 2015
