While the vehicle is stationary, the sensors
will not detect an object/person
approaching from the side. Also, at vehicle
start-up, the vehicle has no sensor
information about side objects/persons.
In both of these situations, an X displays
on the Touch screen in the vehicle's blind
spots.
The front, side, and outer rear sensors
monitor a 1.2 m area around the vehicle.
The inner rear sensors monitor a 1.8 m
area at the rear of the vehicle.
The Parking aid system automatically
activates when Reverse (R) gear is
selected, then the front, rear, and side
sensors are activated. The sensors remain
active until the vehicle's speed reaches 16
km/h (10 mph).
If a forward gear is subsequently selected,
the front, rear, and side sensors remain
active until the vehicle’s speed reaches 16
km/h (10 mph).
By pressing and holding the Parking aid
switch (1) for three seconds, the Parking
aid system enters into an Auto-on mode,
activating the front and side sensors when
the vehicle's speed decreases to less than
10 km/h (6 mph), in a forward direction.
The Parking aid switch LED lamp
illuminates to confirm. Auto-on mode
remains active after the ignition is
switched off and on again. To disable the
Auto-on mode, press and hold the Parking
aid switch for three seconds. The Parking
aid switch LED lamp extinguishes to
confirm.
Note: To manually enable the front and
side sensors in a forward direction, press
the Parking aid switch for less than three
seconds. The LED lamp illuminates to
confirm. Press the switch again to disable
the temporary use of this setting. The LED
lamp extinguishes to confirm.
Note: The Parking aid system is always
temporarily disabled if the vehicle's speed
exceeds 16 km/h (10 mph).
When objects are detected, the system
emits a warning tone, which increases in
frequency as the vehicle gets closer to an
object. The tone becomes constant when
the object is within 300 mm of the vehicle.
Note: The warning tone stops when the
distance between the vehicle and the
object remains constant.
Note: If the Parking aid system does not
detect an object likely to come into
contact with the vehicle, it does not
display any tracking information on the
Touch screen.
Note: The sensors must be kept clean to
maintain accuracy and performance. See
211, SENSORS AND CAMERAS.
PARKING AID SYSTEM FAULT
If a system fault is detected, a long
high-pitched tone is emitted and the
switch indicator flashes. Also, a graphic
and a Parking aid message is displayed
on the Touch screen. Contact a Retailer/
Authorised Repairer as soon as possible.
REAR CAMERA
It remains the driver's
responsibility to detect obstacles
and estimate the vehicle's
distance from them when
reversing.
120
Parking aids
© Jaguar Land Rover Limited 2015
