Circuits protectedFuse
colour
Rating
(Amps)
Fuse
number
Passenger compartment fuse box.Orange4023*
Starter motor (diesel).Green3024
Anti-lock braking system (ABS).Orange4025
ABS.Orange4026*
Passenger compartment fuse box.Orange4027*
Heater blower.Orange4028*
Electric trailer brake (Australia).Green3029*
Headlamp washers.Blue1530
Horns.Blue1531
Air conditioning.Red1032
Horn. Heated front screen. Fuel system.Tan533
Heated front screen - left side.Orange4034*
Heated front screen - right side.Orange4035*
Engine management system. Air conditioning.Tan536
Fuel system.Yellow2037
Headlamp - left side.Yellow2038
Headlamp - right side.Yellow2039
Adaptive Front Lighting System (AFS) - right headlamp.Tan540
AFS - left headlamp.Tan541
Headlamps. Headlamp levelling. Rear view camera.Tan542
---43
Heated steering wheel.Red1044
Steering wheel.Tan545
*Land Rover recommends that these fuses
should only be serviced by a Retailer/
Authorised Repairer.
229
Fuses
