Circuits protectedFuse

colour

Rating

(Amps)

Fuse

number

Left side rear heated seat.Yellow20FA9

Right side rear heated seat.Yellow20FA10

Diesel Exhaust Fluid (DEF).Orange40FA11

---FA12

Lower fuse box

Circuits protectedFuse

colour

Rating

(Amps)

Fuse

number

---FB1

Adaptive cruise control (ACC).Tan5FB2

Instrument panel.Red10FB3

Gateway module.Tan5FB4

Adaptive suspension.Green30FB5

Powered tailgate.White25FB6

Auxiliary heater.Tan5FB7

Driver's/passenger seat switches.Blue15FB8

Head-Up Display (HUD).Red10FB9

Blind Spot Monitor (BSM).Red10FB10

Audio amplifier.Orange40FB11

Audio amplifier.Yellow20FB12

Underfloor fuse box

Circuits protectedFuse

colour

Rating

(Amps)

Fuse

number

Touch screen. Front integrated control panel.Blue151

Audio amplifier.Red102

Gesture tailgate.Red103

Navigation. Telephone.Red104

Audio head unit.Blue155

Audio video input/output panel.Blue156

233
