Renesas R8C/20 User Manual

B - 3
NOTE:
1. Blank columns are all reserved space. No access is allowed.
Address
Register Symbol Page
0100h Timer RA Control Register TRACR
121
0101h Timer RA I/O Control Register TRAIOC
121, 124, 127,
129, 131, 134
0102h Timer RA Mode Register TRAMR
122
0103h Timer RA Prescaler Register TRAPRE
122
0104h Timer RA Register TRA
123
0105h
0106h LIN Control Register LINCR
347
0107h LIN Status Register LINST
348
0108h Timer RB Control Register TRBCR
138
0109h Timer RB One-Shot Control Register TRBOCR
138
010Ah Timer RB I/O Control Register TRBIOC
139, 141, 145,
148, 153
010Bh Timer RB Mode Register TRBMR
139
010Ch Timer RB Prescaler Register TRBPRE
140
010Dh Timer RB Secondary Register TRBSC
140
010Eh Timer RB Primary TRBPR
140
010Fh
0110h
0111h
0112h
0113h
0114h
0115h
0116h
0117h
0118h Timer RE Counter Data Register TRESEC
260
0119h Timer RE Compare Data Register TREMIN
260
011Ah
011Bh
011Ch Timer RE Control Register 1 TRECR1
261
011Dh Timer RE Control Register 2 TRECR2
261
011Eh Timer RE Count Source Select Register TRECSR
262
011Fh
0130h
0131h
0132h
0133h
0134h
0135h
0136h
0137h Timer RD Start Register TRDSTR
172, 186, 202,
215, 225, 239
0138h Timer RD Mode Register TRDMR
172, 186, 203,
216, 226, 240
0139h Timer RD PWM Mode Register TRDPMR
173, 187, 203
013Ah Timer RD Function Control Register TRDFCR
174, 188, 204,
216, 227, 240
013Bh Timer RD Output Master Enable Register 1 TRDOER1
189, 205, 217,
228, 241
013Ch Timer RD Output Master Enable Register 2 TRDOER2
189, 205, 217,
228, 241
013Dh Timer RD Output Control Register TRDOCR
190, 206, 242
013Eh Timer RD Digital Filter Function Select
Register 0
TRDDF0
175
013Fh Timer RD Digital Filter Function Select
Register 1
TRDDF1
175
Address
Register Symbol Page
0140h Timer RD Control Register 0 TRDCR0
176, 191, 206,
218, 229, 243
0141h Timer RD I/O Control Register A0 TRDIORA0
177, 192
0142h Timer RD I/O Control Register C0 TRDIORC0
178, 193
0143h Timer RD Status Register 0 TRDSR0
179, 194, 207,
219, 230, 244
0144h Timer RD Interrupt Enable Register 0 TRDIER0
180, 195, 208,
220, 231, 245
0145h Timer RD PWM Mode Output Level Control
Register 0
TRDPOCR0
209
0146h Timer RD Counter 0 TRD0
180, 195, 209,
220, 232, 2450147h
0148h Timer RD General Register A0 TRDGRA0
181, 196, 210,
221, 232, 2460149h
014Ah Timer RD General Register B0 TRDGRB0
181, 196, 210,
221, 232, 246014Bh
014Ch Timer RD General Register C0 TRDGRC0
181, 196, 210,
221, 246014Dh
014Eh Timer RD General Register D0 TRDGRD0
181, 196, 210,
221, 232, 246014Fh
0150h Timer RD Control Register 1 TRDCR1
176, 191, 206,
229
0151h Timer RD I/O Control Register A1 TRDIORA1
177, 192
0152h Timer RD I/O Control Register C1 TRDIORC1
178, 193
0153h Timer RD Status Register 1 TRDSR1
179, 194, 207,
219, 230, 244
0154h Timer RD Interrupt Enable Register 1 TRDIER1
180, 195, 208,
220, 231, 245
0155h Timer RD PWM Mode Output Level Control
Register 1
TRDPOCR1
209
0156h Timer RD Counter 1 TRD1
180, 195, 209,
2320157h
0158h Timer RD General Register A1 TRDGRA1
181, 196, 210,
221, 232, 2460159h
015Ah Timer RD General Register B1 TRDGRB1
181, 196, 210,
221, 232, 246015Bh
015Ch Timer RD General Register C1 TRDGRC1
181, 196, 210,
221, 232, 246015Dh ,
015Eh Timer RD General Register D1 TRDGRD1
181, 196, 210,
221, 232, 246015Fh
01B0h
01B1h
01B2h
01B3h Flash Memory Control Register 4 FMR4
388
01B4h
01B5h Flash Memory Control Register 1 FMR1
387
01B6h
01B7h Flash Memory Control Register 0 FMR0
386
01B8h
01B9h
01BAh
01BBh
FFFFh Option Function Select Register OFS
23, 114, 381
