10-16 Additional Components Rexroth EcoDrive Cs Drives
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
• Screw on the encoder adapter (see figure below):
• Screw in the bolt (1)
• If present, screw in screw (2) of ground connection into the bolt
• Screw in second screw (3)
geberadapter_anschrauben.fh7
2
1
3
1: Bolt
2: Screw of ground connection
3: Screw
Fig. 10-18: Screw on the encoder adapter
