5-26 Electrical Connections Rexroth EcoDrive Cs Drives
DOK-ECODR3-DKC**.3-CS*-PR02-EN-P
Connection encoder - emulation
max. cable length: 40 m
max. allowed capacitance per length unit
– between the outputs
– between output and 0 V
5 nF
10 nF
shielding
see also Fig. 5-52: Connection of
incremental actual position value output and
Fig. 5-56: Output of absolute actual
position value in SSI format
double shield protected
CAUTION
Damaging potential by utilizing non and single
shielded cables.
⇒
Utilize double shielded cables.
Note: The output of the actual position value is updated every
1000 µs. Due to the non synchronized processing of these
signals in the controller sampling inaccuracies and beat effects
arise.
Cable
