21 August 2006

3-20

AREA A

3.4.4 INFEED TRANSPORT WHEEL

1. Remove Infeed transport module ( 3.4.3 ).

2. Remove nuts [A] (

x3 ).

3. Remove E-clip [B] (

x1 ).

[A]

[B]
