Replacement
Adjustment
21
August 2006
Replacement
Adjustment
3-1
1
3.3.5
UPPER TOP
COVER
COVERS
[A]
[C]
[D]
1.
Open the T
op Cover
.
2.
Remove screws [A] (
x2 ).
3.
Lift front end of upper T
op Cover and pull so that the studs [B] exits the rubber
bushings [C] at the rear side of the Cover Feeder or Cover Feeder Dummy
.
4.
Lift off the Upper
T
op Cover [D].
[B]
96
