Spec-3
18 April 2006
Specication
PERIPHERALS SPECIFICATION
COVER FEEDER CF5010
Specications Remarks
Maximum Speed Same as BK5010
Standard Paper Sizes Same as BK5010
Paper Weight (Minimum) 70 gsm/ 18 lb. Bond
Paper Weight (Maximum) Same as BK5010
Cover Feeder Capacity 20 mm (approx 200 sheets of 80gr/m2 paper)
Off-line Use Possible (Together with Booklet maker)
Weight 7 kg / 15.4 lb or less
Dimensions (L x H x D) 310 x 190 x 530 mm / 12.2 x 7.5 x 20.9”
Power Source From BK5010
TRIMMER TR5010
Specications Remarks
Speed Same as BK5010
Standard Paper Sizes Same as BK5010 Custom sizes are available
Default trim length 4,5 mm / (11/64”) Adjustable in 0.5 mm steps
Minimum trimming 1 mm / (0.0394 in)* Adjustable in 0.5 mm steps
Maximum trimming 16 mm / (0.63”) Adjustable in 0.5 mm steps
Paper Weight (Minimum) Same as BK5010
Paper Weight (Maximum) Same as BK5010 Engine Duplex: 216 gsm
Input / Output Sheets Same as BK5010
Input / Output Sheets Same as BK5010
Off-line Use Possible (Together with Booklet maker)
Weight 65 kg / 143.3 lb or less
Dimensions (L x H x D) 360 x 900 x 620 mm / 14.2 x 35.4 x 24.4”
Power Source From BK5010
* When trimming SRA3 (450 mm) Booklets minimum trimming is 5 mm, when trimming 18” Booklets mini-
mum trimming is 9 mm.
SPECIFICATIONS
