Installation

04 October 2007

1.5 TRIMMER INSTALLATION

1.5.1 ACCESSORY CHECK

[A]

Check the quantity and condition of the accessories in the box against the follow-

ing list:

NOTE: - The Installation Box is located in the trim bin on the Trimmer.

- The trim bin is tie wraped on the rear side.

- Trimmer fan is bubble wrapped and located inside the Trimmer.

- The Rail Extension is located in the packing material

Description Q’ty

A. Communication cable between the Booklet maker .............. 1

and the Trimmer

B. Powercord between the Booklet maker and Trimmer .......... 1

C. Trimmer fan assy ................................................................. 1

D. Rail extension ...................................................................... 1

Plugs and screws ................................................................ 4

E. Cable protector ..................................................................... 1

F. Cable protector sticker ......................................................... 1

G. Cable holder ......................................................................... 1

[B] [C]

[D]

[E] [F] [G]

TRIMMER INSTALLATION
