6-6
5 May 2006
Interlock Switch
BK-S16 / S17
Set Counter
BK-Q4
Staple Detection Lead
BK-Q19 / BK-Q20
BK-Q8
6.1.4 OUTFEED UPPER VIEW
Outfeed cover removed
ELECTRICAL COMPONENT LIST
BK-Q36
