1-43
Installation
04 October 2007
1. Remove the Trimmer front cover by removing the screws [A] ( x 5).
2. Move the Trimmer up to the Booklet maker.
[A]
1.5.3 ADJUSTMENTS
Height adjustment
TRIMMER INSTALLATION
