Ricoh bk5010 - Detailed Self-Diagnostic Mode

5-20
21 August 2006
5.3.3 DETAILED SELF-DIAGNOSTIC MODE
The main self-diagnostic mode, Diagnostics, is available from the service program
mode. Diagnostics checks the EEPROM, the sensors and the motors. If a fault is found
it will be displayed as a fault code. To remedy the fault, go to Fault Code Description
( 4.1).
1. Undock the BK5010 from the copier.
2. Enter the service program mode (
5.1.1).
3. Remove the two stapler heads (
3.4.12).
4. Close the top cover.
5. If a Cover Feeder is installed, make sure the adjustable side guides
are in their innermost position.
6. Go to Diagnostics. Press OK.
7. Press Run.
8. If a fault code is displayed, go to Fault Code Descriptions.
( 4.1). Locate the fault code and follow the procedure .
9. When the fault has been remedied, go through this procedure
again until no faults are found
NOTE: Look through Jam History in the Service mode to locate oth
-
er faults or to establish a pattern of repeated faults ( 5.1.1).
10.
IMPORTANT:
ALWAYS POWER OFF THE SYSTEM WHEN EXITING THE DIAG-
NOSTIC MODE.
IMPORTANT
Reectingpaperpathsensorscanbefaultyalthoughnotdetectedbythe
diagnostics. If they have a failure state equal to constantly unblocked, it will
not be detected as it is the correct home position state. Should this failure
occur it will be detected by the run time diagnostics.
Executing Diagnostics
Follow this procedure to execute the diagnostics.
SELF-DIAGNOSTIC MODE
