5.1.2 SERVICE PROGRAM MODE TABLES
Check Motors and function
SERVICE PROGRAM MODE
Booklet Maker
Motor Normal Reading Function
BK-M1 14V ±2V, ≈0.90m/s Infeed Motor transports the set to the stapling
section.
BK-M2 9V ±2V Back Jogger Motor jogs the sheets together
lengthwise.
BK-M3 200mm - 325mm Side Jogger Motor adjusts the position of the
side guides for different paper sizes. It also
jogs the sheets together sidewise and guides
the set through the machine.
BK-M4 15V ±2V Stapler Motor drives the staples into the set
and drives the clinchers that clinches the staple
legs at.
BK-M5 24V ±2V Set Transport Motor transports the set from the
stapling area to the folding area.
BK-M6 18V ±2V, 0.25m/s Fold Roller Motor folds and compresses the set
and transport it out of the Booklet Maker.
BK-M7 19V ±2V Fold Knife Motor pushes the set up through the
fold rollers.
BK-M8 12V ±2V Fold Stop Gate Motor makes a slight jog to en-
sure set is straightened up before folding.
BK-M9 ≈269mm - ≈460mm Staple/Fold Position Motor adjusts the position
of the staple stop, fold stop and back jogger for
different paper sizes.
BK-M19 14V ±2V, 0.4m/s Pre Infeed Motor transports the set to the sta-
pling section.
Cover Feeder
Motor Normal Reading Function
CF-M15 12V ±2V, 0.4 m/s Feed Motor separates the top sheet from the stack
and transports the sheet towards the Drive Motor.
CF-M16 4V ±2V, 0.3 m/s Drive Motor, together with Feed Motor, transports
the sheet into the Booklet Maker.
CF-M17/
M18
20V Blower Motor blows air between the sheets in the
Cover Feeder as a pre-separation.
