5-5
Service
Tables
21 August 2006 SERVICE PROGRAM MODE
Trimmer
Motor Normal Reading Function
TR-M1 22V ±2V, ≈0.70m/s Transport/Knife Motor transports the booklet in
and out ≈0.70m/s of the Trimmer unit. It also
functions as a second Trim Knife Motor when
reversed. In Service mode, only transport direc-
tion can be run.
TR-M2 28V ±2V Trim Knife Motor cycles knife to cut the book-
let.
TR-M3 28V ±2V Stop Gate Motor moves the stop gate up to
stop the booklet to be trimmed and down when
transporting it out.
TR-M4 21V ±2V,
≈120-220mm
Length Adjustment Motor adjusts the position of
the stop gate for different booklet sizes.
TR-M5/M6 24V Blower Motor blows the trimmed shingle (cut
paper edge) down to the scrap bin.
Book Folder
Motor Normal Reading Function
BF-M1 17,5V ±2V Transport Belt motor transports the booklet in
and out of the Book Folder.
BF-M2 N.A. Stop gate motor moves the stop gate up and
down to stop the booklet in correct position.
BF-M3 N.A. Clamp motor opens and closes the Set clamp,
holding the booklet in place when the Roller
motor are performing the book folding action.
BF-M4 12V ±2V,
≈0.35 m/s
Roller motor performs the book folding action.
Stacker
Motor Normal Reading Function
ST-M1 15V ±2V or
29V ±2V
Stacker Motor transports the set on the belt
stacker.
