5-18
21 August 2006
1. Switch Off the Main Power Switch.
2. Remove rear cover (
3.3.1 ).
3. Run the BF5010 MD6DC v1.00.exe* le (* v1.00 is an example - use latest ver
-
sion) and follow the instruction in the program, or according to the latest bulletin.
NOTE: The DIP switches must be in the off position.
OFF
5.2.6 Downloading to PCB MD6DC D in Book Folder.
SERVICE PROGRAM MODE
CAUTION
ESD Hazard! ESD (Electrostatic Discharge) can cause software crashes,
data and/or communications problems. Failure to use proper ESD pro-
cedures will cause damage to electronic components (example: PCBs).
ESD problems can be minimized by maintaining all machine ground con-
nections, ensuring the proper handling of circuit boards and sensors. Use
ESD protection when working near PCBs. Failure to use ESD protection is
likely to result in a PCB failure ( 3.1 ).
