6. DETAILED SECTION DESCRIPTIONS
6.1 ELECTRICAL COMPONENT LIST
Page Grid
code
BK-M1 Infeed motor ................................................................................................ 6-8 .......... E2
BK-M2 Back Jogger motor ................................................................................... 6-10 .......... D2
BK-M3 Side jogger motor ..................................................................................... 6-10 .......... F2
BK-M4 Stapler motor ............................................................................................... 6-9 ........ H20
BK-M5 Set transport motor ..................................................................................... 6-9 ........ E20
BK-M6 Fold roller motor ......................................................................................... 6-3 ........ H20
BK-M7 Fold knife motor ..................................................................................6-3 / 6-9 ........ E13
BK-M8 Fold stop gate motor .................................................................................. 6-7 ........ E16
BK-M9 Staple / Fold positioning motor ................................................................. 6-7 ........ C19
BK-M19 Pre-Infeed motor ......................................................................................... 6-4 ..........G7
ST-M1 Stacker motor ............................................................................................ 6-11 ........ A20
BK-Q1 Paper Infeed sensor .................................................................................... 6-8 .......... H2
BK-Q2 Infeed motor sensor (located on motor M1) ............................................. 6-8 .......... E2
BK-Q3 Back jogger home position sensor ......................................................... 6-10 ..........G2
BK-Q4 Saddle stapling start sensor ...................................................................... 6-6 .......... N2
BK-Q7 Fold stop sensor ......................................................................................... 6-7 ........ D16
BK-Q8 Outfeed sensor ....................................................................................6-6 / 6-7 .......... N2
BK-Q9 Fold roller sensor ........................................................................................ 6-3 ........ F13
BK-Q10 Staple / Fold positioning motor sensor (loc. on mot M9 ) ....................... 6-7 ........ D19
BK-Q11 Staple / Fold home position sensor .......................................................... 6-4 ..........G7
BK-Q12 Side jogger motor sensor (located on motor M3) .................................. 6-10 ..........G2
BK-Q13 Side jogger home position sensor .......................................................... 6-10 .......... H2
BK-Q14 Stapler home position sensor .................................................................... 6-9 ........G13
BK-Q15 Fold knife home position sensor ............................................................... 6-9 ..........G7
BK-S16 Interlock switch ........................................................................................... 6-6 ...........J2
BK-S17 Interlock magnet ......................................................................................... 6-6 ...........J2
BK-Q19 Staple detection lead (rear side) ................................................................ 6-6 ...........J4
BK-Q20 Staple detection lead (front side) .............................................................. 6-6 ...........J4
BK-Q35 Docking position sensor ............................................................................ 6-6 ........M16
BK-Q36 Thick Set sensor ......................................................................................... 6-6 ........ S17
BK-Q37 Fold Gap sensor .......................................................................................... 6-4 ........ R16
BK-SOL1 Stop gate solenoid ...................................................................................... 6-9 ........ F20
BK-SOL2 Stop gate release solenoid ......................................................................... 6-9 ........ F20
PCB CPU ”A” ....................................................................................................... 6-3 .......... L6
PCB Copier Interface ”E” .................................................................................... 6-3 .......... L8
PCB Interlock ”D” ................................................................................................ 6-4 ........ L17
PCB MD6DC ”B” .................................................................................................. 6-4 .......... E9
PCB MD6DC ”C” .................................................................................................. 6-4 ........G16
PCB MD3DC ”H” .................................................................................................. 6-4 ............I5
PCB Addon ”F” .................................................................................................... 6-3 ........O17
PCB Soft start ...................................................................................................... 6-3 ........ N10
PCB Interlock switch ........................................................................................... 6-3 ...........J3
