Ricoh bk5010 - 1.3.3 ADJUSTMENTS

1-13
Installation
04 October 2007
1.3.3 ADJUSTMENTS
1. Remove screws [A] and remove the Bookler maker front cover ( x5).
2. Remove screws [B], loosen screw [C] and remove the Bookler maker rear
cover ( x5).
[A]
[B] [C]
BOOKLET MAKER INSTALLATION
