2-1
19 April 2006
Preventive
Maintenance
2. PREVENTIVE MAINTENANCE SCHEDULE
2.1 PM TABLE
NOTE: Amounts mentioned as the PM interval indicate the number of sets.
PM TABLE
BK5010 125K 250K 375K 500K NOTE REFERENCE
Paper paths C C C C Blower Brush
Sensors C C C C Blower Brush
Booklet quality I I I I Inspect Section 3.9
Stapler assembly
Clinchers (2x) L L L L Oil, Every 20K 3.4.17
Drive bars (2x) L L Grease 501 3.4.16
Stapler heads (2x) I R I R Inspect, Replace if
needed
3.4.12
Stapler Drive Bar I L I L Grease 501 3.4.15
Folder assembly
Fold knife drive bars
(2x)
L L Grease 501
Fold stop bars (2x) L L Grease 501
Length adjustment
shaft
L L Grease 501 3.6.2
Fold roller bearings
(x6, x2 bracket)
L L Grease: KS660: SHI 3.6.10
Cams to Upper fold
rollers (2x)
L L L L Grease: KS660: SHI 3.6.11 Item [J]
Drive
Driving belt / Fold
transmission
I I I R Inspect, Replace if
needed
3.6.7
Fold transmission
coupling assy.
I I/R I I/R Inspect. Replace if
needed.
3.6.9
CF5010 125K 250K 375K 500K NOTE REFERENCE
Paper paths C C C C Blower brush
Sensors C C C C Blower brush
Feed rollers (5x) C C/R C C/R Alcohol CF 3.2.3
Paper seperator pad C C/R C C/R Alcohol CF 3.2.3
Drive shaft tires (3x) C C C R Alcohol CF 3.2.7, 3.2.8
Symbol key: C: Clean, R: Replace, L: Lubricate, I: Inspect
CAUTION
If any of the checkpoints or other parts show indication of wear at any
point, replace the part. When lubricating, clean the surface if necessary
before applying new lubricant.
