COVER FEEDER INSTALLATION
1.4.3 ENABLING THE COVER FEEDER
1. Power on the Booklet Maker.
2. Enter the service mode on the Booklet Maker by pressing and holding the
leftmost menu button while powering on the Booklet Maker.
NOTE: Do not enter the service mode through the Tools menu.
3. Key in the password.
4. Scroll down to CF5010 Service and press the OK button.
5. Press the CHG button, so the “Installed:” is set to YES.
6. Press the OK button.
7. Perform a Cover Feeder motors Calibration according to section (
5.5 ).
8. Perform a Cover Feeder DSD sensor Calibration according to section (
5.5 ).
9. Make sure that the stapler heads are removed, according to section
( Service Manual BK5010 3.4.12 ).
10. Perform a self diagnosis.
- Scroll up to Diagnostic and press the OK button.
- Press the RUN button.
- If the Diagnostic is OK, continue.
11. Power off the Booklet Maker.
12. Reinstall the stapler heads according to section (
Service manual
BK5010 3.4.12 ).
