5-12
21 August 2006
1. Access the service menu and note the following EEPROM
values:
Index 1, 2, 3, 16 and 20 to 26.
2. Make sure the main power to the Booklet maker is switched
off.
3. Press and hold the leftmost and rightmost button on the Control
Panel.
4. Switch ON the main power switch.
5. Release the buttons on the Control Panel when the text CLEAR
-
ING EEPROM is shown on the LCD. This will be followed by
text DONE on the LCD.
6. Key in the password, press the OK button.
7. Press the ESC button.
8. Switch off the main power to the Booklet maker.
9. Switch on the main power switch.
- Default EEPROM values are restored.
5.1.3 EEPROM RESET
If minor logic problems arise the EEPROM reset procedure can be initiated. All data
in the EEPROM will be cleared including jobs, jam history etc. The only data not
cleared are:
Followed by this procedure it is advised to perform the Paper Size Reset in order to
also reset the paper size parameters that have a great importance in the operation
of the machine ( 5.4).
Followed by this procedure it is advised to set Index 16, TR5010. Knife Zero, in
order to make sure that this specic Trimmer is set up correctly for this specic
Booklet maker ( 1.4.5).
Counters:
- Staple
- Fold
- Trim knife
- Cover feed
SERVICE PROGRAM MODE
