6-3
5 May 2006
Detailed
Description
6.1.1 FRONT VIEW
CPU PCB
Interlock switch PCB
F2 F3 F4
CapacitorTransformer
Rectier
BK-M4
BK-M6BK-Q9
Panel Switches
LCD
Main Power SW
Softstart PCB
ELECTRICAL COMPONENT LIST
Set Counter
Addon PCB
