Ricoh bk5010 User Manual

5-6
21 August 2006
Check Solenoids and function
Booklet Maker
Solenoid Normal Reading Function
BK-SOL1 Will be actuated
for appr. 30 sec.
Stop Gate Solenoid moves the staple stop down
and the set transport rollers up/down.
BK-SOL2 Will be actuated
for appr. 5 sec.
Stop Gate Release Solenoid releases the staple
stop when latched in down position.
SERVICE PROGRAM MODE
Book Folder
Solenoid Normal Reading Function
BF-SOL1 Will be actuated
until sensor BF-
Q6 is actuated
Will be actuated
until sensor BF-
Q6 is actuated
Belt drive engagement solenoid
BF-SOL2
BF-SOL3
BF-SOL4
