Removal
1. Remove outfeed cover (
3.3.4 ).
2. Remove the paper guide [A] by pressing it against the rear side of the Booklet
maker.
3. Remove Fold distance bracket (
3.6.10 ).
4. Remove nuts [B] and bearing brackets [C] on the front and rear side of the
booklet maker ( x2 ).
5. Loosen nuts [D] on the front and rear side of the Booklet maker (
x4 ).
6. Remove springs [E] on the front and rear side of the Booklet maker (
x4 ).
NOTE: Use the Caster tool to remove the springs.
NOTE: Bearings [F] ( x2 ) are pressed on to the axle journals from factory and
can therefore not be removed.
7. Gently remove the Lower folder rollers.
Replacement
1. Reinstall the Lower folder rollers.
2. Reinstall the bearings [F] ( x2 ) on the rear side of the Booklet maker.
NOTE: On the newer type of folder rollers, the bearings are allready pressed
on to the axle journals from factory.
NOTE: Make sure to lubricate, with Molybdenum grease, according to
( 3.6.10).
3. Reinstall springs [E] on the front and rear side of the Booklet maker (
x4 ).
4. Insert the Caster tool, with the pointed end, in the hole [G].
NOTE: Insert the Caster the whole way.
5. When the Caster tool is in it’s most inner position, tighten the nut [D].
NOTE: Repeat step 4 and 5 for all four of the springs.
6. Reverse the rest of the removal procedure.
NOTE: Make sure to lubricate, with Molybdenum grease, according to
( 3.6.10).
