Rigol MSO2000A Series Programming Guide

2 Command System RIGOL
MSO2000A/DS2000A Programming Guide
2-305
:TRIGger:SHOLd:SLOPe
Syntax
:TRIGger:SHOLd:SLOPe <slope>
:TRIGger:SHOLd:SLOPe?
Description
Set or query the edge type of setup/hold trigger.
Parameter
Name Type Range Default
<slope> Discrete {POSitive|NEGative} POSitive
Return Format
The query returns POS or NEG.
:TRIGger:SHOLd:STIMe
Syntax
:TRIGger:SHOLd:STIMe <NR3>
:TRIGger:SHOLd:STIMe?
Description
Set or query the setup time of setup/hold trigger.
Parameter
Name Type Range Default
<NR3> Real 2ns to 1s 50ns
Explanation
This command is available when the hold type (refer to the
:TRIGger:SHOLd:TYPe command) is set to
SETup or SETHOLd.
Return Format
The query returns the setup time in scientific notation.
