Rockwell Automation Publication 450L-UM001D-EN-P - December 2019 59
Chapter 5
System Configuration
An authorized person must perform system configuration by setting the DIP
switches at the receiver plug-in. First set the DIP switches and then mount the
light curtain and establish the electrical connections.
Tabl e 19
and Ta b le 2 0 show which plug-ins are available and which functionality
can be selected with the receiver plug-in.
The blanking and the muting plug-in can be used to operate a 450L-B safety light
curtain, but no muting, blanking, or beam coding functionality can be selected.
Table 19 - Functionalities Available for 450L-B Safety Light Curtain
Table 20 - Functionalities Available for 450L-E Safety Light Curtain
Description
Transmitter Plug-in Receiver Plug-in Universal Plug-in
450L-APT-PW-5 450L-APT-PW-8
ON/OFF
450L-APR-ON-5
EDM
450L-APR-ED-8
Blanking
450L-APR-BL-5
Muting
450L-APR-MU-8 450L-APU-UN-8
Number of Connection Pins 5 8
(1)
5858 8
Number of DIP Switches 004888 12
Low Range Activation — — X X X X X
Start Mode Selection ——— X — X X
EDM ——— X — X X
Transmitter and Receiver Functionality—————— X
Blanking —————— —
Muting —————— —
Beam Coding —————— —
(1) The 8-pin M12 for the transmitter is simply for the convenience of specifying two 8-conductor cordsets for the system.
Description
Transmitter Plug-in Receiver Plug-in Universal Plug-in
450L-APT-PW-5 450L-APT-PW-8
ON/OFF
450L-APR-ON-5
EDM
450L-APR-ED-8
Blanking
450L-APR-BL-5
Muting
450L-APR-MU-8 450L-APU-UN-8
Number of Connection Pins 5 8
(1)
585 8 8
Number of DIP Switches 00488 8 12
Low Range Activation — — X X X X X
Start Mode Selection ——— X — X X
EDM ——— X — X X
Transmitter and Receiver Functionality————— — X
Blanking ———— X X —
Muting ————— X —
Beam Coding ———— X X X
(1) The 8-pin M12 for the transmitter is simply for the convenience of specifying two 8-conductor cordsets for the system.
