Rockwell Automation Publication 450L-UM001D-EN-P - December 2019 63
System Configuration Chapter 5
For 450L-E light curtain only: If DIP 8 is set to OFF: blanking can be activated
and DIP 9 to DIP12 provide a selection of different blanking configurations, see
Tabl e 25
.
If pin 8 is set to ON: Muting muting is activated and DIP 9 to DIP 12 a selection
of different muting configurations, see Table 26 on page 63
.
Tabl e 25
shows the function and default settings for the M12 8-pin muting
receiver plug-in (450L-APR-MU-8) inserted in a 450L-E transceiver stick;
DIP 8 = OFF.
Table 25 - Function and Default Settings
Table 26 on page 63 shows the function and default settings for the M12 8-pin
muting receiver plug-in (450L-APR-MU-8) inserted in a 450L-E transceiver
stick; DIP 8 = ON.
Table 26 - Function and Default Settings
Switch Number Switch Function Default Description
9 450L-E only
Teach-in blanking
OFF OFF: Disabled
ON: Enabled
10 Combination activates one
of the following
configurations:
• No reduced resolution
• Reduced resolution 1
lens
• Reduced resolution 2
lenses
OFF • DIP 10: OFF, DIP 11: OFF:
Reduced resolution
disabled (Default)
• DIP 10: ON, DIP 11: OFF:
Reduced resolution 1
beam
• DIP 10: OFF, DIP 11: ON:
Reduced resolution 2
beams
• DIP 10: ON, DIP 11: ON:
Invalid selection (error)
11 OFF
12 — OFF —
Switch Number Switch Function Default Description
9 450L-E only
Combination activates one
of the following muting
configurations:
OFF • DIP 9: OFF, DIP 10: OFF, DIP 11:
OFF
No muting
• DIP 9: OFF, DIP 10: ON, DIP 11:
OFF
2L muting sensors connected
to connection plug-in
• DIP 9: OFF, DIP 10: ON, DIP 11:
ON
2L muting sensors connected
to I/O cascading plug-in
• DIP 9: ON, DIP 10: OFF, DIP 11:
OFF
2T muting sensors connected
to connection plug-in
• DIP 9: ON, DIP 10: OFF, DIP 11:
ON
2T muting sensors connected
to cascading plug-in
• DIP 9: ON, DIP 10: ON, DIP 11:
ON
4T muting sensors connected
to cascading plug-in
10 OFF
11 OFF
12 — OFF —
