Rockwell Automation Publication 450L-UM001D-EN-P - December 2019 83
Installation and Wiring Chapter 6
Figure 50 - Connection Cable Guide Options
Figure 51 and Figure 52 show possible mounting when attaching to extruded
aluminum profiles.
Figure 51 - 450L Safety Light Curtain Mounted on an Extruded Aluminum Profile Using the
Standard Top/Bottom Mounting Bracket
Figure 52 - 450L Safety Light Curtain Mounted Backwards on an Extruded Aluminum Profile
Using the Standard Top/Bottom Mounting Bracket
