3-4 Frame 3A and 3B Installation
PowerFlex® 700L Liquid-Cooled Drive User Manual
Publication 20L-UM001D-EN-P
Figure 3.3 Frame 3B Input Filter Bay Power Wiring and Installation Dimensions
T/L3
S/L2
R/L1
35.5 (1.40)
76.4 (3.01)
82.6 (3.25)
34.8 (1.37)
26.8 (1.05)
44.5 (1.75)
615.0 (24.23)
600
(23.6)
233
(9.2)
Max
800
(31.5)
2200
(86.6)
535
(21.1)
1500
(59.1)
2256
(88.8)
Max
157.7 (6.21)
82.6 (3.25)
Ø 14.3
(
Ø 0.56)
Typ.
Ø 28.6
(
Ø 1.13)
Dimensions are in millimeters and (inches).
735
(28.9)
Approximate Weight kg (lbs.)
Input Filter Assembly
861.8 (1900)
