Roland VS-2400CD Owner’s Manual www.RolandUS.com 387
30—VGA Main Display Universal Elements
This chapter describes the areas of the VGA main display that are always visible no
matter how the rest of the display changes. These are the:
• menus • control bar
• PAN knob strip • clipping indicators
• F buttons • status strip
• remaining space status strip
The illustration on Page 382 shows where these elements are located on the VGA.
VGA Menus
The menus at the top of the VGA display give you quick mouse access to all of the
features found in the VS-2400CD’s onboard menus, and also contain items unique to
the VGA main display. To select an item from a menu:
1. Click the desired menu with your mouse to display the
menu’s contents.
2. Move the cursor over the desired menu item to highlight it in
blue and click the item with your mouse.
An arrow to the right of a menu
item signifies additional choices presented in a
submenu. Hold you mouse cursor over the main menu
item, drag rightward and down to select the desired
item from the submenu and click your mouse.
To close a menu, click elsewhere on the screen or press EXIT/NO.
The PROJECT Menu
The PROJECT menu contains an assortment of options that relate to an
entire project.
Menu item: See:
NEW Page 92
RELOAD Page 388
NAME Page 95
PROTECT Page 95
OPTIMIZE Page 96
SPLIT Page 99
EXPORT Page 105
PROJECT LIST Page 89
STORE Page 388
SHUTDOWN Page 78
