4—Setting Up and Basic Operations
62 www.RolandUS.com Roland VS-2400CD Owner’s Manual
Connect a PS/2 Mouse and PS/2 ASCII Keyboard
A mouse and ASCII keyboard can make operation of the VS-2400CD even easier. The
VS-2400CD supports the use of a PS/2-type mouse and PS/2 keyboard. A PS/2 mouse is
included with your VS-2400CD. A PS/2 keyboard must be purchased separately.
Many of the VS-2400CD’s operations can be performed using a mouse instead of the
VS-2400CD’s top-panel controls, as described on Page 68. A mouse also allows you to
operate the VS-2400CD from the screen of a connected VGA monitor purchased
separately)—see Page 381. You can a range of operations—and navigate the
VS-2400CD—using a connected ASCII keyboard (Page 70).
Connect the included mouse to the rear-panel PS/2 MOUSE jack. Connect your
keyboard to the PS/2 KEYBOARD jack.
Connect a VGA Monitor
When you connect a color VGA monitor (purchased separately) to your VS-2400CD,
your VS-2400CD is even easier to use. By manipulating its controls onscreen using your
mouse, everything becomes a simple matter of pointing and clicking. You can use the
VGA as your main display and the VS-2400CD’s internal LCD as a supplemental Info
Display, or the other way around. See Chapter 29, starting on Page 381 to learn more.
You can use any standard VGA display that has a refresh rate from 60-75 Hz. Connect
your monitor’s DB-15-type VGA cable to the VS-2400CD’s rear-panel VGA OUT jack.
Connect Monitors or Headphones
The connections you’ll make depend on how you’ll be listening to the VS-2400CD:
• If you’re going to be listening to the VS-2400CD through DS-90A or DS-50A
monitors, you can connect the VS-2400CD’s COAXIAL OUT or its OPTICAL OUT
to the monitors’ COAXIAL or OPTICAL DIGITAL INPUT. Make sure the DS-90’s or
DS-50A’s Digital Input Select Switch is set to the type of digital connection you’ve
decided to use, and that its Input Select Switch is set to DIGITAL INPUT. See your
DS-90A or DS-50A Owner’s Manual for more information.
• If you’re using other monitors, connect the VS-2400CD’s ANALOG MULTI
OUTPUTs 7 and 8 to the left and right inputs, respectively, of your speaker system.
• If you’re using headphones, connect them to the PHONES jack.
Connect All Other Devices
Connect any other devices to the appropriate VS-2400CD jacks or connectors. If you’re
unsure which jack or connector to use, consult the device’s documentation.
You may need to activate your ASCII keyboard. See the keyboard settings on Page 64.
When using one of the VS-2400CD’s DIGITAL OUTs for monitoring, you’ll need to
configure them as described in “If You’re Using DS-Series Monitors” on Page 73.
