SAM4S SPS-300 Series Electronic Cash Register AU Service Mode Programming • 135
IRC Options
NOTE: When IRC feature is activated, All register number in the IRC network have to be start from
#1 and be numbered contiguously. If one unit is removed from the IRC network, you need
to fill the gap in order to make the register number contiguous and then change following
settings accordingly.
The following screen image shows the example of register number 1 in a 4 unit IRC network.
1. At the SM control lock position menu, press 7 for IRC Option programming. The IRC
OPTIONS screen displays:
2. Press PAGE DOWN to view the remainder of the IRC OPTIONS menu:
3. Refer to the table below to fill the fields on the IRC OPTIONS screen.
4. Press the CLEAR key to finalize and return to the SERVICE MODE screen.
IRC Options Table
Page Field Description
REG#
Enter the IRC number of this register (1-16).
STORE#
Enter the store number. (Do not change this if not advised
to do so)
FROM REG#
Enter the first register number in the IRC system.
TO REG#
Enter the last register number in the IRC system.
IRC RETRIES
Each retry equals approximately 0.5 seconds.
SHARE KP REG#
Enter the Register# connected to common shared KP. Please
set CHECK # function key accordingly.
SHARE CHKTRACK REG#
Enter the Register# to manage Check# file. Please set
CHECK # function key accordingly.
IRC OPTIONS
#SHARE CHKTRACK REG#(1-16) 2
Å
IRC OPTIONS
REG# (1-16) 1
Å
STORE# 000000
FROM REG# 1
TO REG# 4
IRC RETRIES(0-99) 3
#SHARE KP REG#(1-16) 1
