136 • Service Mode Programming SAM4S SPS-300 Series Electronic Cash Register AU
RS232C/USB Port 1/2/3/4 Options
1. At the SM control lock position menu, press 8, then select proper RS232C Port by enter the
number represent the port for programming.
2. The appropriate PORT PROGRAM screen displays (Port #1 for example):
3. At each field, press ENTER (CASH) to view the selections. Enter the digit representing your
selection from the pop-up window.
4. Press PAGE DOWN to view page 2 of the RS232C port program:
5. Press PAGE DOWN to view page 3 of the RS232C port program:
RS232 PORT
1. RS232 PORT 1
2. RS232 PORT 2
3. RS232 PORT 3
4. RS232 PORT 4
PORT 1 PROGRAM pg3
INITIAL FEEDING LINE ON KP
(0-20) 0
Å
ENDING FEEDING LINE ON KP
(0-20) 7
INITIAL FEEDING LINE ON SLIP
(0-20) 0
PORT 1 PROGRAM pg2
STOP BITS (0:1 1:2) 0
Å
DEVICE FUNCTION 1
--------------------------------
0:NONE 1:PC 2:SCL
3:RJ 4:RP 5:KV
6:SCAN 7:COIN 8:EFT
9:POLE
PORT 1 PROGRAM pg1
BAUD RATE 6
Å
0:9600 1:1200 2:2400
3:4800 4:19200 5:38400
6:57600 7:115200
PARITY CHECK 0
0:NONE 1:ODD 2:EVEN
DATA BITS
