4.1.42 TCPS — TC PRE-SCALAR REGISTER: E6H, BANK1
Bit Identifier .7 .6 .5 .4 .3 .2 .1 .0
RESET Value
0 – – – 0 0 0 0
Read/Write
R/W – – – R/W R/W R/W R/W
Timer C Clock Source Selection
0 Internal clock source
.7
1 CMP0 output
.6–.4 Not used for S3F84B8.
Timer C Pre-Scalar Bits .3–.0
TC CLK = TC CLK/(2TCPS); Pre-scalar values above 12 are invalid.
NOTE: When Timer 0 is working in one 16-bit timer mode, the clock is determined by TCPS.
