4.1.24 P0INT — PORT 0 INTERRUPT CONTROL REGISTER: E3H, BANK0
Bit Identifier .7 .6 .5 .4 .3 .2 .1 .0
RESET Value
– 0 0 0 0 – 0 0
Read/Write
– R/W R/W R/W R/W – R/W R/W
.7 Not used for S3F84B8.
P0.6/INT5 Interrupt Enable/Disable Selection Bits
0 Disables interrupt.
.6
1 Enables interrupt.
P0.5/INT4 Interrupt Enable/Disable Selection Bits
0 Disables interrupt.
.5
1 Enables interrupt.
P0.4/INT3 Interrupt Enable/Disable Selection Bits
0 Disables interrupt.
.4
1 Enables interrupt.
P0.3/INT2 Interrupt Enable/Disable Selection Bits
0 Disables interrupt.
.3
1 Enables interrupt.
.2 Not used for S3F84B8.
P0.1/ INT1 Interrupt Enable/Disable Selection Bits
0 Disables interrupt.
.1
1 Enables interrupt.
P0.0 / INT0 Interrupt Enable/Disable Selection Bits
0 Disables interrupt.
.0
1 Enables interrupt.
