4.1.11 FLAGS — SYSTEM FLAGS REGISTER: D5H, BANK0
Bit Identifier .7 .6 .5 .4 .3 .2 .1 .0
Reset Value
x x x x x x 0 0
Read/Write
R/W R/W R/W R/W R/W R/W R R/W
Addressing Mode
Register addressing mode only
Carry Flag (C)
0 Operation does not generate a carry or borrow condition.
.7
1 Operation generates a carry or borrow into high-order bit 7.
Zero Flag (Z)
0 Operation results in a non-zero value.
.6
1 Operation results in zero value.
Sign Flag (S)
0 Operation generates a positive number (MSB = “0”).
.5
1 Operation generates a negative number (MSB = “1”).
Overflow Flag (V)
0
Operation result is  +127 and > -128.
.4
1 Operation result is > +127 or < -128.
Decimal Adjust Flag (D)
0 Completes Add operation.
.3
1 Completes Subtraction operation.
Half-Carry Flag (H)
0 No carry-out of bit 3 or no borrow into bit 3 by addition or subtraction.
.2
1 Addition generated carry-out of bit 3 or subtraction generated borrow into bit 3.
Fast Interrupt Status Flag (FIS)
0 Interrupt return (IRET) in progress (when read).
.1
1 Fast interrupt service routine in progress (when read).
Bank Address Selection Flag (BA)
0 Bank 0 is selected.
.0
1 Bank 1 is selected.
