S3F84B8_UM_REV 1.00 23 MECHANICAL DATA
23-1
23 MECHANICAL DATA
23.1 OVERVIEW OF MECHANICAL DATA
S3F84B8 is available in a 20-pin DIP package (Samsung: 20-DIP-300A) and a 20-pin SOP package (Samsung:
20-SOP-375).
Figure 23-1
and Figure 23-2 show the 20-DIP-300A and 20-SOP-375 package dimensions, respectively.
NOTE: Dimensions are in millimeters.
26.80 MAX
26.40
  0.20
(1.77)
20-DIP-300A
6.40 0.20
#20
#1
0.46    0.10
1.52    0.10
#11
#10
0-15
0
.
2
5
+
0
.
1
0
-
0
.
0
5
7.62
2.54
0.51 MIN
3.300.30
3.250.20 5.08 MAX
Figure 23-1 20-DIP-300A Package Dimensions
