6.3.23 DECW — DECREMENT WORD
DECW dst
Operation: dst  dst – 1
The contents of destination location (which must be an even address) and the operand following
that location are treated as a single 16-bit value decremented by one.
Flags: C: Unaffected.
Z: Set if the result is “0”; cleared otherwise.
S: Set if the result is negative; cleared otherwise.
V: Set if arithmetic overflow occurred; cleared otherwise.
D: Unaffected.
H: Unaffected.
Format:
Bytes Cycles Opcode
(Hex)
Addr Mode
dst
opc dst 2 8 80 RR
8 81 IR
Examples: Given R0 = 12H, R1 = 34H, R2 = 30H, register 30H = 0FH, and register 31H = 21H:
DECW RR0  R0 = 12H, R1 = 33H
DECW @R2  Register 30H = 0FH, register 31H = 20H
In the first example, destination register R0 contains the value 12H and register R1 contains the
value 34H. The statement “DECW RR0” addresses R0 and the following operand R1 as a 16-bit
word and decrements the value of R1 by one, leaving the value 33H.
NOTE: A system malfunction may occur if you use a Zero flag (FLAGS.6) result together with a DECW instruction.
To avoid this problem, it is recommend that you use DECW, as shown in the following example:
LOOP: DECW RR0
LD R2,R1
OR R2,R0
JR NZ,LOOP
